| 类型 | M3激光反射传感器 | M4激光反射传感器 | M6激光反射传感器 | |
| 型号 | NPN常开 | LF-M3NO | LF-M4NO | LF-M6NO |
| PNP常开 | LF-M3PO | LF-M4PO | LF-M6PO | |
| NPN常闭 | LF-M3NC | LF-M4NC | LF-M6NC | |
| PNP常闭 | LF-M3PC | LF-M4PC | LF-M6PC | |
| 检测距离 | 30mm | 50mm | 150mm | |
| 光点大小 | 1mm | 1mm | 1.5mm | |
| 光源 | 红色激光（660nm） | |||
| 响应时间 | 5ms | |||
| 灵敏度调整 | 电位器调整 | |||
| 指示灯 | 黄色LED灯 | |||
| 空载电流 | 9mA | |||
| 输出电流 | 150mA | |||
| 过载保护垫 | 200mA | |||
| 电压降 | 1V | |||
| 迟滞范围 | 10-15% | |||
| 漏电电流 | 0.01mA | |||
| 保护电路 | 反接保护,短路保护 | |||
| 电源 | 12～24VDC ±10% | |||
| 环境温度 | 0℃～+50℃无冻结 | |||
| 外壳 | 不锈钢 | |||
| 线缆 | 2m | |||
LF-M3NO；LF-M3NC；LF-M4NO；LF-M4NC；LF-M6NO；LF-M6NC
LF-M3PO；LF-M3PC；LF-M4PO；LF-M4PC；LF-M6PO；LF-M6PC
LF-M3NO；LF-M3PO；LF-M3NC；LF-M3PC
LF-M4NO；LF-M4PO；LF-M4NC；LF-M4PC
LF-M6NO；LF-M6PO；LF-M6NC；LF-M6PC
